KW Suspension Clubsport - 2 Way BMW M3 E90 E92 1M Not Equipped With EDC

KW Suspension Clubsport - 2 Way BMW M3 E90 E92 1M Not Equipped With EDC

SKU:KWA-35220867

Regular price $4,094.00 USD
Regular price Sale price $4,094.00 USD
Sale Unavailable

KW Clubsport: 2 Way - These set ups were specifically designed by using the optional adjustable top mounts, suspension geometry can be adjusted to the requirements of the tires and the intended use.
These adjustable top mounts coupled with the independently adjustable rebound and compression dampening technology individual set up adjustments according to vehicle load, tire characteristics and different track conditions. Clubsports meets all needs for the road and the race track guaranteeing excellent handling, best performance, great agility and fantastic lap times.
The exclusive KW patented system has dual level valves that allow for adjustment of the rebound dampening for your road comfort and the compression dampening that controls the driving dynamics.

Check out our install video here

 Feature

  • Independently adjustable rebound and compression damping technology
  • Stainless steel technology "inox-line"
  • Continuous lowering
  • High-quality components for a long-term durability
  • Adjustable rebound damping with 16 precise clicks
  • Adjustable compression damping with 12 precise clicks
  • Unique independent damping force adjustment
  • Optional spherical bearing aluminum top mounts

Lowering adjustment ranges

Front from 0.4" to 1.5"

Rear from 0.2" to 1.4"

 Springrates in lbs/inch

Front 630

Rear 685

 Top Mount

Front / Rear : Camber / OE*

* OE Top Mounts Are Not Included



Listing of all vehicles this part can be used with

11-12 BMW 1series M Coupe (E82)
08-13 BMW M3 (E90/E92) not equipped with EDC (Electronic Damper Control) Sedan, Coupe
The images shown are for illustration purposes only and may not be an exact representation of the product.
